Misting System - STARTER v5 (MistKing)

Based on MistKing's new 24V diaphragm pump, capable of running up to 10 nozzles. This misting system is virtually silent. Pump can run dry with no damage. Nozzles are equipped with a check-valve which greatly reduces the drip after misting is done.

This Misting Kit includes:

• 24V DC misting pump, capable of running up to 10 nozzles. Pump is very robust and can run dry.
• Pump is adapted for 1/4" tubing and includes vibration dampening rubber feet.
• Pump power adapter. (cUL listed)
• 1 Value L misting assembly. Assembly is tested and it includes a super low flow check-valved spray tip, custom crafted in black with an average droplets size of ~50 microns. Check-valved tips greatly reduces the post mist drip. These nozzles can be adjusted and positioned in any direction. Can be securely fastened to any surface up to 0.625" (5/8") or 1.5 cm thick. This misting assembly is patented at USPTO.
• Reservoir bulkhead with O-ring and plug.
• 15 feet of 1/4" black opaque tubing
• Digital Seconds Timer ST-24 - with instructions.
• 5 tubing clips with screws
• Reference manual

Pump is adapted for 1/4" push in fittings and carries a 2 year warranty. This pump can silently run 1 nozzle or as many as 10 nozzles. We do not ship reservoir buckets with these kits. No need to add to the shipping cost for something that can be picked up locally for a few dollars. These misting systems come with instructions and push in bulkhead fitting to convert any bucket or container into a reservoir. Plastic pails cost from $3-$8 retail depending on size at any local larger hardware store.
